Description
Prime Guard® Spin‑On Oil Filters deliver dependable engine protection built for today’s demanding conditions. With 300+ PSI burst strength, these filters are engineered for durability and performance. Each filter features high‑quality cellulose or cellulose‑synthetic blend media that provides 95% filtration efficiency at 30 microns. A robust NBR gasket ensures a secure, leak‑free seal, while the anti‑drainback valve helps prevent dry starts and reduces engine wear. Designed and tested to USCAR‑36 specifications—Prime Guard filters ensure consistent fit, quality, and performance across applications. All new‑car warranties remain fully intact, and every filter is backed by a manufacturer defect warranty.
Features:
- Prime Guard® Spin‑On Oil Filters with 300+ PSI burst strength for reliable performance
- Spin-on canister design with cellulose or cellulose-synthetic blend media
- 95% filtration efficiency at 30 microns captures contaminants for engine protection
- NBR seal gasket provides robust, leak-free seal when properly installed
- Anti-drainback valve prevents dry starts by keeping oil in filter during shutdown
- Installation: tighten until contact, then 3/4 to full turn additional for proper seal
- Designed and tested to USCAR-36 specifications for quality fit and function across applications.
- All new car warranties remain in effect when installing Prime Guard oil filters
| Duty Type | LD |
| Media Material | Synthetic Blend |
| Height | 2.58 IN |
| Outer Diameter Top | 2.69 in |
| Inner Diameter Top | Closed |
| Thread Size | M20x1.5 IN |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve Setting | 8-11 PSI |
| Burst Pressure | 300 psi |
| Flow Rate | 9-11 GPM GPM |
| Class | B |
| Style | Spin-On Lube Filter |
| Brand | Part Number |
|---|---|
| AC DELCO | X 4029 E |
| AGCO | 330148296 |
| ALLOMATIC | 5859 |
| ALTROM | 2OMD002 |
| AMC | NO-251 |
| AMSOIL | EA15K12 |
| ARIENS | 21500001 |
| ASAS | SPC 901 |
| ASHIKA | 10-01-121 |
| ATLAS | M33 |
| ATP | B198, RX74, TF-198 |
| AUTO EXTRA | 618-51365, 618-51365MP |
| AUTO EXTRA GKI | 61651365 |
| AUTO PRIDE | CF113AP |
| BALDWIN | B1400, BT23631, PA4453 |
| BECK-ARNLEY | 0410753, 0410798, 0418055, 0418136, 0418181, 0448001 |
| BELRAY | SV57800 |
| BOMAG | 5740004 |
| BOSCH | 0 451 103 292-3B4, 0 451 104 025, 0 451 104 068 RENAULT, 0 986 AF2 428, 3300, 72181, 72230WS, L3300, P 4025 |
| BOSCH (KSN) | P3292 |
| BOSCH DISTANCE PLUS | D3300 |
| BRITISH LEYLAND | T1210200 |
| CAR CARE PARTS | OF6607 |
| CARQUEST | 83739, 85365, Z 1297, Z 1611 |
| CARQUEST RED | B4622, B4622MP |
| CARQUEST RED NEW | R85365, R85365MP |
| CARQUEST TRANSMISSIONS | 96064 |
| CASE | 72276225, VV11930535150 |
| CASITE | CF113 |
| CASTROL SFX | CAS6607 |
| CATERPILLAR | 3769707 |
| CHAMP | LS 198, T714 |
| CHAMPION | COF 100134 S, COF 102137 S, F 134/606, F 137, F 137/606 |
| CHAMPION FILTERS | COS3593A, COS6607 |
| CHRYSLER_MOPAR (ALSO SEE MITSUBISHI) | 0FE00310, 5069273, F0PH2876 |
| CITGO | C2876, C4610, C4612, C4622 |
| CLEAN FILTERS | DO 949 |
| COMLINE | EOF042, EOF190 |
| COOPERS | Z 1611 |
| COOPERSFIAAM | FT5389, FT5730 |
| CROSLAND | 2283 |
| DEFENSE | DL3330, DL6607 |
| DELPHI | FX0185 |
| DENSO | 1501008 |
| DEUTSCH | D371 |
| DITCH WITCH | 194691, 452410 |
| DONALDSON | P502067 |
| DURALAST | D1014, DG6607, MD1008 |
| DYNALUBE | D4612 |
| ECOGARD | S4612, X4612 |
| ECOGUARD | S4612 |
| ENGINE LIFE | EL6607 |
| FACTORY MOTOR | R1365 |
| FEBI-BILSTEIN | 38927 |
| FEDERATED | LF113F, PG4612EXF, PG4612F |
| FILMAR | SO8242, SO8524 |
| FIRESTONE | TF2876, TF4622 |
| FLEETGUARD | LF3403, LF3692 |
| FORD | E9GZ6731A, B6M6-14-302 |
| FRAD | 20.37.84/110 |
| FRAM | FP6607, FPS6607, PH5885 , PH6607, PH9928, TG6607, XG6607, DL6607 |
| FRAM DRIVE | FD6607 |
| FRAM ENDURANCE | FE3600, FE6607 |
| FRAM EXTRAGUARD | PH6607 |
| FRAM FORCE | FF6607 |
| FRAM TITANIUM | FS6607 |
| FVP OIL FILTER | R1365 |
| FVP RELIAGUARD FILTERS | R1365 |
| GK INDUSTRIES | TF1205 |
| GREASE MONKEY | GM4622 |
| GROUP 7 | V4612, V4622 |
| GUD | Z 223, Z 282, Z 350, Z 470 |
| HALFORDS | HOF274 |
| HASTINGS FILTERS | LF113, TF170 |
| HENGST | H97W09, H97W12 |
| HERITAGE | HL6607 |
| HOFFER | 7605131, 7605319/11 |
| HONDA | 15400-PFB-014, 15400679033 |
| INGERSOLL-RAND | 54477096, 54647680 |
| IPS | IFL-3121 |
| JAKOPARTS | J1311028 |
| JAPAN PARTS | FO-121, FO-121S, FO-197S, FO-315S, JFO-121, JFO-K01 |
| JIFFY LUBE | HL6607, JL4622, L14622 |
| JLG | 7017980, 7018103 |
| JOHN DEERE | M 806418, M811409, MIA11714, TY26277 |
| K&N | HP1008, KN-191, SO-1008 |
| KANGA | L115905 |
| KAWASAKI | 160971064 |
| KENDALL | K41 |
| KOLBENSCHMIDT | 489-OS, 50 013 906, 906-OS |
| KOLPIN | 051365 |
| KRALINATOR | L266 |
| KUBOTA | HH150-32430 |
| LONG | A0653039 |
| LUBER-FINER | PH2876 |
| LUBERFINER | PH 2876, PH2876-1 |
| LUCAS (ALSO SEE CAV) | EDL 963, F6600 |
| LUCAS (LUCAS-TRW) | EDL 963 |
| M-FILTER | MH 3390 |
| MAHLE/KNECHT | LX 2881, OC 195, OC 259, OC 475, OC337, OC338, OC445, OC711, OX 192D |
| MANN-FILTER BASE | W 67/1 |
| MANN-HUMMEL FILTERS | W67/1 |
| MAPCO | 61217, 61219 |
| MAZDA | 1N0314302, 1WPE14302, B 6Y1-14302, B 6Y1-14302-9A, B 6Y1-14302-A, B6Y114302ACA, B6Y214302, B6YZ14302 |
| MEAT & DORIA | 15319/11, 15558 |
| MECAFILTER (LAUTRETTE) | ELH4212, ELH4299 |
| MERCURY MARINE | 35-8M0162831, 8M0162386, 8M0162831, 8M0162832 |
| MEYLE | 16-14 322 0002, 16-14 322 0008 |
| MICRO-GARD | GL14612, MGL6607 |
| MICRO-GARD-WIX | MGL51365 |
| MIGHTY | M4459, M4622, T4612SP |
| MILEGUARD | MO6607 |
| MITSUBISHI | MD 348631, MD134953 |
| MOBIL | MO2622BP, MO4622 |
| MOBIL 1 AIO | M1-108A |
| MOBIL ONE | M1-108A, M1108 |
| MOTAQUIP | VFL 393, VFL 525 |
| MOTORCRAFT | FL 816 |
| MOTORCRAFT AIO | FL-816 |
| MULLER FILTER | FO193 |
| MÜLLER FILTER | FO289 |
| NAPA GOLD | 1365 |
| NAPA PLATINUM | 41365 |
| NAPA PROSELECT | 21365, 21365MP |
| NAPA SILVER | 31365 |
| NASCAR SELECT | 91365 |
| NIPPARTS | J1310303, J1310500, J1311036 |
| NIPPON-MICRO | T61 |
| NISSAN | 15208-00QAG, 3R0076150, 3R0076150M |
| ONAN | 1857444 |
| OREILLY PROTEC MP | PTL51365MP |
| OREILLY PROTEC MP-NEW | PXL51365MP |
| P.B.R. | BC-1297, BC-1352 |
| PARTS PLUS | PG4612EX, PH2876, PH2876EX |
| PARTSMASTER | 61365 |
| PARTSMASTER GKI | 88365 |
| PENTIUS | PLB6607 |
| PHILLIPS 66 | PO1365 |
| PIT STOP | PSL41 |
| POLARIS | 3070131 |
| POWER FLO | SL14622 |
| PREMIUM GUARD | PG4612EX, PT1285 |
| PRIME GUARD | POF4612, V4615 |
| PRO-TEC | 168, PTL51365MP |
| PRO/GAUGE | PGO4622 |
| PROFESSIONAL’S CHOICE | Q4612, Q4622 |
| PROMOTIVE | PH4612, PH4615, PH4622 |
| PRONTO | PO4612EX, PO4615, PO4615P, PO6607 |
| PROTEC-NEW | PXL51365, PXL51365MP |
| PUREPRO | L4612, T1285 |
| PUREZONE | 8-51365 |
| PURFLUX | LS871, LS871A , LS924 |
| PUROLATOR | L 14612, L 14622, L 17754, P1285, PER4622, PL14612, PL14622, PBL14612, L14612, TL14612, TL14612BP |
| PUROLATOR SYNTHETIC | PSL14612 |
| PUROLATOR TECH | TL14612BP |
| QUAKER STATE | QS6607 |
| RENAULT | 77 00 112 686, 77 00 863 124, 77 00 867 824, 77 00 869 029, 82 00 257 642 |
| REPCO | ROF135, ROF162 |
| ROBIN | 2576730101 |
| ROYAL PURPLE | 102876 |
| RYCO | Z436, Z445 |
| SAAB | 32005769 |
| SAKURA | C 1711, C 1809, C-2514, C-5205, C-9002, C1719, C18151, C8030, C8036 |
| SCHUPP / SF FILTER | SP 4579, SP 4786 |
| SECURITY | PH2876, SO2876 |
| SERVICE CHAMP | 89189, HP4622, OF4622, WPH2876 |
| SERVICE PRO | M4622 |
| SHELL | SH531, SH538 |
| SOFIMA | S 3424 R |
| SPX FILTRAN | F379 |
| STEINER | 4166483-21 |
| STENS | 120137 |
| STP | S6017A, S6607, S6607XL |
| SUBARU | 38325AA031, 38325AA032, 38325KA000 |
| SUPERTECH | MP6607, ST6607 |
| TECNOCAR | R193, R289 |
| TENNANT | 9006427 |
| TEXACO | TFC531, TFC531B, TFC538 |
| TIRES PLUS | TF2876 |
| TORO | 1001892, 1158189 |
| TRUST | PH2876 |
| TVI | TVIV4612, TVIV4622 |
| U.F.I. | 23.424.00, 23.470.00 |
| UNION SANGYO | C218, C431 |
| UNIPART | GFE 387 |
| UNOCAL 76 | PF1365 |
| VAICO | V46-0224, V46-0235 |
| VALEO | 586011, 586033 |
| VALUCRAFT | V6607 |
| VALVOLINE | L2876, VO54 |
| VERA | 1001725 |
| VOLVO | 11713228 |
| WACKER | 1000003052 |
| WACKER NEUSON | 5200004741 |
| WALMI | WS6607 |
| WARNER | PH2876 |
| WEB | W6607 |
| WHITE | 330148296 |
| WIX | 51365 |
| WIX EUROPE | WL7204 |
| WIX FILTERS | WIX FILTERS, 51365, 51365XP |
| WIX XP | 51365XP |
| WOODGATE | WGL9056 |
| YANMAR | 11930535160 |
| YUIL FILTERS | YOMI-014 |
Fits Vehicles
- JAC SEI 2 (2024)
- Mitsubishi Mirage G4 (2024)
- JAC J7 (2021-2024)
- Mazda 3 Sport (2011)
- Nissan Micra (2017-2019)
- Mazda 2 (2013-2015, 2022)
- Renault Fluence (2011-2017)
- Renault Koleos (2009, 2011-2017)
- Suzuki Equator (2009-2012)
- Mazda 626 (1997-1999, 2001-2002)
- Mazda Protege5 (2002-2003)
- Mazda 323 (1993, 1995)
- Mazda Protege (1997-2003)
- Mazda MX-3 (1996)
- Mazda RX-8 (2004-2008)
- Mazda Miata (1994, 1997, 1999-2005)
- Honda Insight (2000-2006)
- Mercury Tracer (1991-1996)
- Mercury Capri (1991-1994)
- Ford Escort (1991-1996)
- Ford Aspire (1995-1997)
