Description
Prime Guard® Spin‑On Oil Filters deliver dependable engine protection built for today’s demanding conditions. With 300+ PSI burst strength, these filters are engineered for durability and performance. Each filter features high‑quality cellulose or cellulose‑synthetic blend media that provides 95% filtration efficiency at 30 microns. A robust NBR gasket ensures a secure, leak‑free seal, while the anti‑drainback valve helps prevent dry starts and reduces engine wear. Designed and tested to USCAR‑36 specifications—Prime Guard filters ensure consistent fit, quality, and performance across applications. All new‑car warranties remain fully intact, and every filter is backed by a manufacturer defect warranty.
Features:
- Prime Guard® Spin‑On Oil Filters with 300+ PSI burst strength for reliable performance
- Spin-on canister design with cellulose or cellulose-synthetic blend media
- 95% filtration efficiency at 30 microns captures contaminants for engine protection
- NBR seal gasket provides robust, leak-free seal when properly installed
- Anti-drainback valve prevents dry starts by keeping oil in filter during shutdown
- Installation: tighten until contact, then 3/4 to full turn additional for proper seal
- Designed and tested to USCAR-36 specifications for quality fit and function across applications.
- All new car warranties remain in effect when installing Prime Guard oil filters
Product Attributes
| Filter Type | Spin-on |
| Filter Media Material | Enhanced Cellulose |
| Micron Rating | 25 |
| Anti-Drain Back Valve | yes |
| Bypass Relief Valve | yes |
| Gasket Type | NBR |
| Height | 3.43 IN |
| Gasket Inside Diameter | 2.42 IN |
| Gasket Outside Diameter | 2.8 IN |
| Gasket Thickness | 0.26 IN |
| Outer Diameter Bottom | 2.95 IN |
| Inside Thread Size | M22xP1.5 |
| Gasket Outside Diameter | 61.7 MM |
| Burst Pressure | 470 PS |
| Bypass Relief Valve Setting | 21-25 PS |
| Brand | Part Number |
|---|---|
| ACDelco | UPF64R |
| Auto Extra | 618-10290 |
| Autopart International | 5001-654061 |
| Baldwin | B7422 |
| Bpro Auto | 1BP00175AA |
| Carquest Extended Performance | P95140 |
| Carquest Premium Filters | 95140 |
| Carquest Standard | R95140 |
| Cartek | CTK64R |
| Casite Filters | CF613 |
| Castrol | CAS12060 |
| Champ | PH488 |
| Champ filters | PH488 |
| Duralast | DC10060 |
| ECOGUARD | S11642 |
| EXXON/MOBIL OIL | M1114A |
| FRAM | PH12060, M1-113A, M1-113 |
| FRAM Drive | FD12060 |
| FRAM Force | FF12060 |
| FRAM Titanium | FS12060 |
| FRAM Tough Guard | TG12060 |
| FVP | R0290 |
| Federated | UPG64R |
| Ford | NU2Z6731F |
| General Motors | 12670058 |
| Gonher | GP2304 |
| Hastings | LF630 |
| LUBER-FINER | PH10064 |
| Luber-finer | PH488 |
| MOBIL OIL | M1113A, M1113 |
| MicroGard | MGL10290 |
| MicroGard Select | MSL10290 |
| Mighty Distributing System | M9509 |
| Motorcraft | FL2127 |
| NAPA Gold Filters | 100290 |
| Napa Proformer | 2100290 |
| PUROLATOR | TL11403, TL11403BP, PL11403, PBL11403 |
| Parts Master | WL610290BP |
| Parts Plus | UPG64R |
| Pennzoil | PZ-194 |
| Performax | PO-194 |
| Prime Guard | POF1403 |
| Pro-Tec | PTL10290 |
| Pronto | UPG64R |
| Protec-New | PTL10290 |
| PureZone | 8-10290 |
| Purolator | L11403 |
| Purolator BOSS | PBL11403 |
| Purolator TECH | TL11403 |
| Quaker State | QS194 |
| Royal Purple | 10-10064 |
| STP | S12060 |
| STP Filters | S12060 |
| Service Champ | WPH488 |
| Service Pro | E11642 |
| Super Tech Filters | ST12060 |
| Valucraft | VC10060 |
| Valvoline | VO-160 |
| WIX FILTERS | WL10290XP, WL10290 |
| Warner Filters | WPH488 |
| Wix | WL10290 |
PRIME GUARD POF1403 Fits Vehicles
- Ford Bronco Sport (2025-2026)
- Ford Bronco (2025)
- Ford Maverick (2025-2026)
- Ford Explorer (2025-2026)
- Ford Ranger (2025-2026)
- Lincoln Nautilus (2024-2026)
- Buick Envista (2024-2026)
- Ford Mustang (2024-2026)
- Lincoln Corsair (2023-2026)
- Ford Escape (2023-2026)
- Chevrolet Cruze NG (2016)
- Cadillac CT5 (2022-2026)
- MG HS (2020-2024)
- Chevrolet Trax (2021-2022, 2024-2026)
- Chevrolet Onix (2021-2025)
- Chevrolet Trailblazer (2021-2026)
- Buick Encore GX (2020-2025)
- Chevrolet Blazer (2019-2022)
- Buick Regal Sportback (2018-2020)
- Buick Regal TourX (2018-2020)
- GMC Terrain (2018-2026)
- Chevrolet Traverse (2018-2019)
- Chevrolet Equinox (2018-2026)
- Buick LaCrosse (2018-2019)
- Buick Envision (2016-2020)
- GMC Acadia (2017-2021)
- Chevrolet Spark Classic (2016-2017)
- Chevrolet Cruze (2016-2019)
- Cadillac CT6 (2016-2018)
- Chevrolet Spark (2016-2022)
- Chevrolet Camaro (2016-2024)
- Buick Encore (2016-2019, 2021-2022)
- Chevrolet Malibu Limited (2016)
- Chevrolet Volt (2016-2019)
- Chevrolet Impala (2015-2019)
- GMC Canyon (2015-2022)
- Chevrolet Colorado (2015-2022)
- Chevrolet Impala Limited (2014-2016)
- Buick Regal (2014-2017)
- Chevrolet Corvette (2014-2026)
- Cadillac CTS (2013-2019)
- Cadillac ATS (2013-2019)
- Chevrolet Malibu (2013-2025)
